Welcome to The Phlatforum PhlatPrinter III

MC Escher locking lizards

Discussion in 'Puzzles' started by kram242, Feb 18, 2011.

  1. kram242

    kram242 Administrator Staff Member

    Offline
    Messages:
    6,311
    Trophy Points:
    13
    Location:
    NJ
    Here's a file I have always wanted to try to make. Neat little puzzle
    Its the Escher Reptiles
    I did my best to get it a close as possible, but its not easy because if you change one side the receiving end has to change as well and it sets off a chain of changes :)
    A little about Escher
    1/4" fan fold
    1/8" stock bit
    150 IPM

    Reptiles
    [​IMG] Attached files [​IMG] [​IMG] [​IMG] [​IMG] [​IMG] [​IMG] MC Esher Lizard.cnc (426.1 KB)Â MC Esher Lizard.skp (2.5 MB)Â

    kram242, Feb 18, 2011
    #1
  2. 3DMON

    3DMON Moderator Staff Member

    Offline
    Messages:
    2,380
    Trophy Points:
    38
    Location:
    Sebastian, Florida
    I love Eshers stuff.

    These lizards are cool! :good:

    3DMON, Feb 18, 2011
    #2
  3. rcav8r

    rcav8r Moderator Staff Member

    Offline
    Messages:
    1,193
    Trophy Points:
    38
    Really cool stuff. I love that interlocking stuff, but never knew what it was called.

    My son loves lizards (just don't ask him about them 'cause he'll tell you WAY more than you would ever want to know), so it looks like I'll be cutting some this weekend.

    THANKS for posting.

    rcav8r, Feb 18, 2011
    #3
  4. theothers

    theothers Administrator Staff Member

    Offline
    Messages:
    761
    Trophy Points:
    18
    Location:
    New Jersey
    Leaping lizards! This file is so cool. It's awesome how it goes together.

    theothers, Feb 18, 2011
    #4
  5. kram242

    kram242 Administrator Staff Member

    Offline
    Messages:
    6,311
    Trophy Points:
    13
    Location:
    NJ
    Thanks y'all :D
    Here's a short crazy video I made of the cutting :)

    I went overboard with the effects but it was fun :fugly:
    Hope you like it
    Mark and Trish

    kram242, Feb 18, 2011
    #5
  6. Crash

    Crash Moderator Staff Member

    Offline
    Messages:
    469
    Trophy Points:
    18
    Location:
    Waco, Texas, USA
    Mark, I hope you are putting that video up on YouTube. It's spectacular!

    I have got to get your source for the music you are using in your vids. Good stuff!

    Crash, Feb 18, 2011
    #6
  7. kram242

    kram242 Administrator Staff Member

    Offline
    Messages:
    6,311
    Trophy Points:
    13
    Location:
    NJ
    LOL thanks Mike I debated it at first but then I put it up there :)
    Just some old skool music I grew up with, still sounds cool to me though ;D
    Mark and Trish

    kram242, Feb 18, 2011
    #7
  8. Tweakie

    Tweakie Member

    Offline
    Messages:
    233
    Trophy Points:
    18
    Location:
    UK
    That is just excellent.
    I will certainly add this project to my list.
    Thank you.

    Tweakie.

    Tweakie, Feb 19, 2011
    #8
  9. kram242

    kram242 Administrator Staff Member

    Offline
    Messages:
    6,311
    Trophy Points:
    13
    Location:
    NJ
    Cool Tweakie! Now are we going to see some of these in acrylic on the laser?! :D
    Mark and Trish

    kram242, Feb 19, 2011
    #9
  10. Tweakie

    Tweakie Member

    Offline
    Messages:
    233
    Trophy Points:
    18
    Location:
    UK
    Certainly will make some with the laser and post pics but it may be a while.

    (I am sure you know this already but Acrylic is one of those few materials which sublimates [changes from a solid to a gas without going through the liquid stage]. The laser vapourises the stuff almost instantly so I have a powerful extraction system to remove the gasses, unfortunately, this also removes the heat in my workshop and it soon drops to outside ambient which is below the temperature at which I want to operate the laser, computer, machines etc. Fortunately spring is on the way, buds are starting to show and Tweakie will soon be up and running again :D )

    Tweakie.

    Tweakie, Feb 20, 2011
    #10
  11. kram242

    kram242 Administrator Staff Member

    Offline
    Messages:
    6,311
    Trophy Points:
    13
    Location:
    NJ
    Can't comer soon enough for us , it been a tough winter here!
    Mark and Trish

    kram242, Feb 20, 2011
    #11
  12. Tweakie

    Tweakie Member

    Offline
    Messages:
    233
    Trophy Points:
    18
    Location:
    UK
    Well we got an unusually mild day today so the laser was back into action. I have always been fascinated by Escher's drawings and it was very rewarding to make some of his lizards. Thanks for the file guys.

    Tweakie.
    [​IMG]

    [​IMG]

    [​IMG]

    Tweakie, Feb 24, 2011
    #12
  13. rcav8r

    rcav8r Moderator Staff Member

    Offline
    Messages:
    1,193
    Trophy Points:
    38
    Hay Tweakie; those came out REALLY nice. Looks a lot better than the blue foam ones I cut :)

    Where in the UK are ya?

    rcav8r, Feb 24, 2011
    #13
  14. Tweakie

    Tweakie Member

    Offline
    Messages:
    233
    Trophy Points:
    18
    Location:
    UK
    Thanks.

    I am in the south east at Southend-on-Sea which was traditionally the Londoners weekend playground. :D

    Tweakie.

    Tweakie, Feb 24, 2011
    #14
  15. rcav8r

    rcav8r Moderator Staff Member

    Offline
    Messages:
    1,193
    Trophy Points:
    38
    We spent 2 weeks in the UK about 2 years ago, but never made it to those parts. Closest was Southampton. We loved all of the UK, what a beautiful area, so diverse.

    rcav8r, Feb 24, 2011
    #15
