Welcome to The Phlatforum PhlatPrinter III

Need help with plugin

Discussion in 'SketchUcam Help' started by Navop, Jul 24, 2011.

  1. Navop

    Navop New Member

    Offline
    Messages:
    28
    Trophy Points:
    1
    Location:
    St-Telesphore, Quebec, Canada
    Ok d/l the new version of phlatscript/sketchUcam, installed ok

    but when I go to parameter the box appears with all the squares where you input
    the info, but their is no comments/ description of what the box on the left is for

    I've done a screen shot of what I mean Attached files [​IMG]

    Navop, Jul 24, 2011
    #1
  2. jovian

    jovian Member

    Offline
    Messages:
    208
    Trophy Points:
    16
    Sorry i missed this before. Have you tried uninstalling all versions then reinstalling the one you want?If this still occurs let me know and we will check for some particular files. Has anyone else seen this?

    jovian, Jul 26, 2011
    #2
  3. theothers

    theothers Administrator Staff Member

    Offline
    Messages:
    761
    Trophy Points:
    18
    Location:
    New Jersey
    This is a strange error. Are you using a Mac? I know that Macs have problem with the web dialog windows. Maybe this is the case? Also, what version of SketchUp are you using? We use SketchUp 7 but we know it to work in SketchUp 8 as well. We think jovian has the right idea, uninstall and then reinstall. Then, check to see that you have these files in the proper place: Google > Google SketchUp 7 > Resources > en-US > (PhlatBoyz.strings).

    And also in Google > Google SketchUp 7 > Tools > you should have a (Phlatboyz folder) as well as the file (Phlatboyztools.rb)

    Just double check to see that all of the files were installed in the correct place.

    theothers, Jul 31, 2011
    #3
  4. TigerPilot

    TigerPilot Well-Known Member

    Offline
    Messages:
    1,578
    Trophy Points:
    48
    I forgot about this post until you've just mentioned it. I went through the constant.rb yesterday and saw this there:
    Maybe that will be the solution.

    TigerPilot, Jul 31, 2011
    #4
  5. kram242

    kram242 Administrator Staff Member

    Offline
    Messages:
    6,311
    Trophy Points:
    13
    Location:
    NJ
    I forgot about that too Yoram.. good find! :good:
    Mark and Trish

    kram242, Aug 1, 2011
    #5
  6. juju7

    juju7 New Member

    Offline
    Messages:
    1
    Trophy Points:
    0
    Hello i am using vista i have sketchup8 installled also the phlatscript addon and have been using it fine i have tried to use it today and have also got a blank dialog box with no fields or values just white boxes. i have tried to uninstall all and re-install but still the same? can eny one help me?

    juju7, Mar 1, 2012
    #6
  7. kram242

    kram242 Administrator Staff Member

    Offline
    Messages:
    6,311
    Trophy Points:
    13
    Location:
    NJ
    juju7 you could try what TigerPilot posted above it may help
    Open your constant.rb file with a notepad editor and find the line that says
    [pre]# -------------------------
    # PhlatScript Features
    # -------------------------

    # Set this to true if you have problems with the parameter dialog being blank or crashing SketchUP
    Use_compatible_dialogs = false[/pre]

    Change the false to true and save it right over the old one. Open SU and see if this helped
    Mark and Trish

    kram242, Mar 2, 2012
    #7
  8. bobt

    bobt New Member

    Offline
    Messages:
    1
    Trophy Points:
    0
    I am also having a problem installing the the phlatscript on Sketchup 8 version 8.0.14346 that I just downloaded last night. I also downloaded the latest Phlatscript from here. The files appear to be in the correct locations as I have been able to determine from searching this site. BUT when I fire up Sketchup and look in windows/proferences/extensions it is not listed at all. It appears that there is some controlling file now in control of the extensions because other items from the tools and resources directories are listed. I am at a loss as to what the problem is at this time.

    Machine
    OS - Windows 7 Home Preminum
    Sketchup 8 8.0.14346
    Phlatscript 0.918 which is what I just loaded from this site.

    Bob Teeter

    bobt, Aug 8, 2012
    #8
  9. kram242

    kram242 Administrator Staff Member

    Offline
    Messages:
    6,311
    Trophy Points:
    13
    Location:
    NJ
    Hi Bob,
    There was talk of them adding some type of new plugin handler. I am not sure how it works
    Your best bet would be to download this version of SketchUp (7.1)
    http://www.phlatforum.com/viewtopic.php?f=96&t=440#p3251
    until we can get a look at why its not working with the latest version of 8
    Hope this helps
    Mark and Trish

    kram242, Aug 9, 2012
